Material Intake
Bag Dump Station
CYprocess bag dump stations — also called sack tip stations or manual dumping booths — let operators empty 10-50 kg bags inside a dust-tight hood. A bag sling holds the sack at working height and a patting device clears the residue, while local extraction keeps the tip zone under slight negative pressure.
Shanghai-built. Drawings come with the quotation, and material certificates are available on request. Factory and documents
1 / 3
Overview
About Bag Dump Station
How this equipment works in powder handling lines and what to consider when selecting it.
Working principle
The bag is opened on a grate inside the hood. A fan draws air from the tip zone through a filter, so airborne fines are captured instead of escaping into the workshop. Product falls through the grate into the transition hopper; lumps and tramp material stay on top, and collected dust returns to the hopper by pulse cleaning.
Options and integration
A bag sling holds the sack at an ergonomic tip height and a patting device empties the residue after tipping. The hood can carry an integral filter or be ducted to a central dust collector, and other options cover de-ironing, vibrating screens, bag collection and weighing. The hopper outlet feeds conveyors, weighers or mixers.
Where it fits in the process
Features
Key Features
Design points that make the Bag Dump Station practical for industrial powder plants.
Specifications
Typical Specifications
Final sizing depends on material properties, capacity and plant layout. Request a project review for a tailored proposal.
Model range
| Model | Size L×W×H (mm) | Power (kW) | Screen | Material |
|---|---|---|---|---|
| CY-BD-800 | 1200 × 800 × 2350 | 1.1 | None | SS304 / SS316L |
| CY-BD-800S | 1200 × 800 × 2350 | 2.2 | 20 mesh | SS304 / SS316L |
CY-BD stations share a 1200 × 800 × 2350 mm frame. The S variant adds a 20-mesh safety screen for agglomerate and tramp removal; contact parts in SS304 or SS316L.
General specifications
| Models | DS-800 (no screen) / ADS-800 (safety screen) |
|---|---|
| Bag size | Typically 10-50 kg per bag |
| Tip capacity | Up to about 10 t/h, operator dependent |
| Dust fan | About 0.75 - 2.2 kW |
| Screen | None (DS) / approx. 20 mesh or vibrating screen (ADS) |
| Construction | Carbon steel / SS304 / SS316L |
| Utilities | 220 V or 380 V; compressed air about 0.6 - 0.8 MPa |
| Options | Bag sling, patting device, de-ironing, vibrating screen, bag collector, weighing |
Materials
Suitable Materials
Powder and granule categories typically specified with a bag dump station. Suitability is confirmed per project from bulk density, particle size, moisture and process conditions.
Food powders
sugar, starch, flour, salt, milk powder, additives
Pharmaceutical solids
API, excipients, granulates
Chemical powders
resins, pigments, coatings, additives
Battery materials
cathode and anode powders
Minerals & metal powders
oxides, fillers, small-batch metal powders
Not sure whether your material will convey? Send us a sample description and we will confirm before quotation.
Industries
Industries Served
Sectors where bag dump station units are specified today.
Project experience
Where this equipment is running
Selected projects that include bag dump station.
Applications
Process Applications
Process points where this equipment is typically installed, from bulk intake through to packing.
Downloads
Catalogs & Datasheets
Technical documents related to this product and our powder handling range.
FAQ
Bag Dump Station FAQ
Common questions about selection, integration and quotation.
Standard stations are designed for 10-50 kg bags, with 25 kg the most common duty. Heavier or unusually shaped bags are reviewed individually, and tip height, grate size and hopper volume are adapted to your handling routine.
