Small Bag Packer
CYprocess small bag packing machines — also called open-mouth baggers or weigh-fill bagging lines — fill 5-50 kg open-mouth bags under electronic weighing control, then pass them to an automatic sewing or sealing station on a guided outfeed conveyor.
Shanghai-built. Drawings come with the quotation, and material certificates are available on request. Factory and documents
1 / 3
Overview
About Small Bag Packer
How this equipment works in powder handling lines and what to consider when selecting it.
Working principle
The bag is placed on the filling spout and held by a roller support while product is fed in. Fast and slow feeding stages bring the weight to the setpoint, the bag is released onto the outfeed conveyor, and the sewing or sealing head closes it. The operator's task is limited to presenting bags.
Options and integration
Screw, gravity and impeller feeding cover different material behaviours, and the touchscreen weigh controller stores recipes and target weights. Options include dust extraction at the spout, de-ironing, heat sealing and a valve-bag filling head for a different bag type.
Where it fits in the process
Features
Key Features
Design points that make the Small Bag Packer practical for industrial powder plants.
Specifications
Typical Specifications
Final sizing depends on material properties, capacity and plant layout. Request a project review for a tailored proposal.
Model range
| Item | CY-SB-25H | CY-SB-25S |
|---|---|---|
| Packing weight (kg) | 20 - 50 | 20 - 50 |
| Speed (bags/h) | 30 - 50 | 40 - 60 |
| Accuracy | ±0.2% | ±0.2% |
| Power (kW) | 6 | 10 |
| Dimensions L×W×H (mm) | 1400 × 800 × 3600 | 1500 × 800 × 2800 |
CY-SB packers fill 20 - 50 kg valve or open-mouth bags. Accuracy depends on the material's flow behaviour and is finally confirmed during commissioning.
General specifications
| Bag type | Open-mouth, sewing or sealing outfeed |
|---|---|
| Weigh range | 5 - 50 kg typical |
| Accuracy | About ±0.2 - 0.5%, application dependent |
| Speed | Approx. 3 - 8 bags/min, material dependent |
| Feeding | Screw / gravity / impeller |
| Control | Touchscreen weigh controller with sewing station panel |
| Outfeed | Belt conveyor with side rails and auto sewing head |
| Air supply | Typically 0.4 - 0.6 MPa |
Materials
Suitable Materials
Powder and granule categories typically specified with a small bag packer. Suitability is confirmed per project from bulk density, particle size, moisture and process conditions.
Food powders
flour, starch, sugar, milk powder, spices
Chemical powders
pigments, resins, additives
Minerals & fillers
limestone, talc, quartz, cement
Plastics & granules
granules, masterbatch, compounds
Feed & fertiliser
compound feed, urea, NPK blends
Battery materials
cathode, anode and precursor powders
Not sure whether your material will convey? Send us a sample description and we will confirm before quotation.
Applications
Process Applications
Process points where this equipment is typically installed, from bulk intake through to packing.
Downloads
Catalogs & Datasheets
Technical documents related to this product and our powder handling range.
FAQ
Small Bag Packer FAQ
Common questions about selection, integration and quotation.
Typically 5-50 kg open-mouth bags, with 25 kg the most common retail and industrial size. Bag length and width are matched by adjusting the spout and the conveyor guides, so changing size is a mechanical set-up rather than a rebuild.
