Horizontal Ribbon Mixer
CYprocess horizontal ribbon mixers — also called ribbon blenders — blend powders and powder-liquid formulations in a U-shaped trough with dual helical ribbon agitators. Batch times typically run from about 5 to 60 minutes depending on the recipe.
Shanghai-built. Drawings come with the quotation, and material certificates are available on request. Factory and documents
1 / 4
Overview
About Horizontal Ribbon Mixer
How this equipment works in powder handling lines and what to consider when selecting it.
Working principle
As the shaft turns, the outer ribbon drives material from both ends toward the middle while the inner ribbon returns it outward. Product also moves radially, forming a continuous convection cycle. The result is a homogeneous blend with gentle handling, and a VFD can adjust batch time and mixing intensity.
Construction and options
Builds range from carbon steel through SS304 to full SS316L, with anti-corrosion or wear coatings where needed. Scrapers can be fitted for cohesive or viscous recipes, liquid can be sprayed into the powder bed, and discharge is by flap, spherical, butterfly or knife gate valve.
Where it fits in the process
Features
Key Features
Design points that make the Horizontal Ribbon Mixer practical for industrial powder plants.
Specifications
Typical Specifications
Final sizing depends on material properties, capacity and plant layout. Request a project review for a tailored proposal.
Model range
| Model | Working volume (m³) | Batch (kg) | Speed (r/min) | Power (kW) | Weight (kg) | L (mm) | C (mm) | H (mm) |
|---|---|---|---|---|---|---|---|---|
| CY-RM-0.3 | 0.18 | 200 | 62 | 5.5 | 600 | 2280 | 680 | 880 |
| CY-RM-0.5 | 0.3 | 300 | 62 | 7.5 | 900 | 2670 | 780 | 1240 |
| CY-RM-1 | 0.6 | 600 | 49 | 11 | 1200 | 3140 | 980 | 1400 |
| CY-RM-2 | 1.2 | 1200 | 33 | 15 | 2000 | 3860 | 1200 | 1650 |
| CY-RM-3 | 1.8 | 1800 | 33 | 18.5 | 2500 | 4460 | 1300 | 1700 |
| CY-RM-4 | 2.4 | 2500 | 27 | 22 | 3500 | 4950 | 1400 | 2000 |
| CY-RM-5 | 3.0 | 3000 | 27 | 30 | 4000 | 5280 | 1550 | 2100 |
| CY-RM-6 | 3.6 | 3600 | 27 | 37 | 4500 | 5530 | 1560 | 2200 |
| CY-RM-8 | 4.8 | 4800 | 22 | 45 | 5000 | 5100 | 1720 | 2500 |
| CY-RM-10 | 6.0 | 6000 | 22 | 55 | 6000 | 5610 | 1750 | 2650 |
| CY-RM-15 | 9.0 | 9000 | 14 | 75 | 7500 | 5820 | 2000 | 2900 |
| CY-RM-20 | 12 | 12000 | 14 | 90 | 10500 | 6300 | 2350 | 3160 |
| CY-RM-30 | 18 | 15000 | 12 | 110 | 13000 | 7000 | 2600 | 3350 |
CY-RM horizontal ribbon mixers, quoted per batch at a 0.5 - 0.6 fill factor for powders of about 0.5 - 0.8 kg/L bulk density. L / C / H are overall length, width and height (mm). Chopper, jacketing and VFD options available — confirm the exact model with our engineers.
General specifications
| Series | WLD horizontal ribbon mixer |
|---|---|
| Mix time | Typically about 5 - 60 min per batch |
| Agitator | Double helical ribbon, inner and outer |
| Construction | CS / SS304 / SS316L; coatings optional |
| Discharge | Flap / spherical / butterfly / knife gate; manual, pneumatic or electric |
| Options | Liquid spray, VFD, full-open cover, choppers, scrapers |
| Batch range | About 70 kg to 21,000 kg per batch (see model range) |
Materials
Suitable Materials
Powder and granule categories typically specified with a horizontal ribbon mixer. Suitability is confirmed per project from bulk density, particle size, moisture and process conditions.
Chemical powders
pigments, dyes, resins, fine chemicals
Battery materials
cathode, anode, conductive carbon
Food powders
flour, milk powder, starch, sugar, additives
Pharmaceutical solids
API, excipients, granulates
Building materials
dry mortar, cement blends, gypsum
Plastics & additives
compounds, masterbatch, fillers
Not sure whether your material will convey? Send us a sample description and we will confirm before quotation.
Industries
Industries Served
Sectors where horizontal ribbon mixer units are specified today.
Project experience
Where this equipment is running
Selected projects that include horizontal ribbon mixer.
Applications
Process Applications
Process points where this equipment is typically installed, from bulk intake through to packing.
Downloads
Catalogs & Datasheets
Technical documents related to this product and our powder handling range.
FAQ
Horizontal Ribbon Mixer FAQ
Common questions about selection, integration and quotation.
It is the usable trough volume below the ribbon, not the geometric volume of the shell. Batch weight follows from it at the material's bulk density, which is why the same mixer gives a different batch weight for a light powder than for a dense one.
