Components
Activation Hopper
CYprocess activation hoppers — also called activating or live-bottom hoppers — pair a conical discharge section with a slowly rotating agitator. The agitator keeps the outlet zone moving, so powders that bridge and rat-hole are discharged steadily instead of in avalanches.
Shanghai-built. Drawings come with the quotation, and material certificates are available on request. Factory and documents
1 / 6
Overview
About Activation Hopper
How this equipment works in powder handling lines and what to consider when selecting it.
Working principle
Product falls into the conical section where a geared agitator turns slowly through the outlet zone. The agitator breaks incipient bridges and keeps the material live above the discharge valve, so downstream feeding stays constant. Speed is low by design — the goal is conditioning, not mixing.
Options and integration
Agitator style, outlet size and drive are selected from the material's flow behaviour. The hopper bolts under silo cones, bag dump hoppers and big-bag discharge frames, and feeds rotary valves, screws or vacuum take-ups. Level switches and vibrators can be combined on the same vessel.
Where it fits in the process
Features
Key Features
Design points that make the Activation Hopper practical for industrial powder plants.
Specifications
Typical Specifications
Final sizing depends on material properties, capacity and plant layout. Request a project review for a tailored proposal.
| Type | Conical hopper with geared agitator |
|---|---|
| Outlet | Sized to rotary valve / screw / vacuum |
| Agitator speed | Low speed, set per material |
| Material | SS304 / SS316L contact parts |
| Mounting | Under silo cone, dump hopper, FIBC frame |
| Extras | Level switch, vibrator, lump breaker |
Materials
Suitable Materials
Powder and granule categories typically specified with a activation hopper. Suitability is confirmed per project from bulk density, particle size, moisture and process conditions.
Poor-flowing powders
TiO2, carbon black, oxides
Fibrous products
fibre fines, biomass
Moist powders
slightly damp filter dust
Food powders
sticky blends, high-fat powders
Not sure whether your material will convey? Send us a sample description and we will confirm before quotation.
Applications
Process Applications
Process points where this equipment is typically installed, from bulk intake through to packing.
Downloads
Catalogs & Datasheets
Technical documents related to this product and our powder handling range.
FAQ
Activation Hopper FAQ
Common questions about selection, integration and quotation.
Vibrators work when the powder only needs a shock to start moving. Once material is cohesive enough to form stable bridges, constant low-speed agitation gives steadier discharge without compacting the product the way knocking can. We choose from the material's flow function and the outlet size.
System partners
Related Products
Equipment commonly paired with Activation Hopper in complete powder handling lines.
Engineering support
Enquire about Activation Hopper
Share your material, capacity and plant layout. Our engineers will confirm sizing and send a tailored proposal.
