Can it run different bag sizes in one shift?

Yes. Belt guides and blade height are adjusted quickly, and bag counting helps verify batch intake. Very different bag formats can be stored as recipes if the machine is ordered with the recipe option.

Where does the dust go?

The cutting chamber runs under slight negative pressure. On the standard build an integral filter collects fines and returns them to the hopper; where a central dust collector exists, the chamber is simply ducted to it.

Material Intake

Small Bag Automatic Unpacking Machine

Name: Small Bag Automatic Unpacking Machine
Brand: CYprocess
Availability: InStock

CYprocess small bag automatic unpacking machines — also called bag slitting or auto bag-breaking stations — feed sealed 5 - 50 kg bags on a belt, cut them open inside an enclosed chamber and separate product from film automatically. Operators never open a dusty bag by hand.

View Details Request a Quote All Products

Shanghai-built. Drawings come with the quotation, and material certificates are available on request. Factory and documents

Automatic small bag unpacking machine with belt conveyor

1 / 2

Overview

About Small Bag Automatic Unpacking Machine

How this equipment works in powder handling lines and what to consider when selecting it.

Working principle

Bags are stacked on the infeed roller table and fed one by one into the cutting chamber. A slitting blade opens each bag along its face, product falls into the discharge hopper and the emptied film passes to the compacting device, which keeps the film from re-entering the product stream. The chamber is kept under slight negative pressure during the whole cycle.

Options and integration

Belt speed, blade pattern and chamber airflow are set from the bag type and product. The hopper outlet feeds vacuum conveying, a screw or a big-bag filling head, and options include bag counting, de-ironing over the outlet and connection to a central dust collector instead of the integral filter.

Where it fits in the process

Material Intake

Conveying

Dosing

Mixing

Packaging

Features

Key Features

Design points that make the Small Bag Automatic Unpacking Machine practical for industrial powder plants.

Automatic infeed, cutting and discharging of 5 - 50 kg bags

Enclosed cutting chamber under slight negative pressure

Film separated and compacted automatically

No manual bag opening — no operator dust exposure

Integral filter or ducting to a central collector

De-ironing and bag counting options

Feeds vacuum, screw or big-bag filling downstream

Specifications

Typical Specifications

Final sizing depends on material properties, capacity and plant layout. Request a project review for a tailored proposal.

Bag weight	5 - 50 kg per bag
Throughput	Set by belt speed and bag size
Cutting	Motorised slitter, pattern per bag type
Dust control	Integral filter or central collector duct
Film handling	Separate discharge with compacting
Construction	SS304 contact parts, SS316L option

Materials

Suitable Materials

Powder and granule categories typically specified with a small bag automatic unpacking machine. Suitability is confirmed per project from bulk density, particle size, moisture and process conditions.

Chemical powders

pigments, resins, masterbatch

Food ingredients

flour, sugar, starch, additives

Battery materials

cathode and anode powders, carbon

Minerals

calcium carbonate, kaolin, oxides

Pharma solids

excipients, granulates (GMP build)

Not sure whether your material will convey? Send us a sample description and we will confirm before quotation.

Applications

Process Applications

Process points where this equipment is typically installed, from bulk intake through to packing.

Automated intake of 25 kg chemical bags

Food ingredient bags in dust-controlled plants

Battery material intake from sealed liners

High-throughput lines replacing manual tipping

Pigment and masterbatch bag feeding

Central raw-material intake rooms

Downloads

Catalogs & Datasheets

Technical documents related to this product and our powder handling range.

All downloads

Product Catalog

CYprocess Powder Handling Product Catalog (2026)

PDF · 3.5 MB

Download

Technical Datasheet

Small Bag Auto Unpacking Machine Datasheet

PDF · 182 KB

Download

Technical Datasheet

Automatic Batching System Datasheet

PDF · 121 KB

Download

Technical Datasheet

Big Bag Packing Machine Datasheet

PDF · 169 KB

Download

FAQ

Small Bag Automatic Unpacking Machine FAQ

Common questions about selection, integration and quotation.

After the bag is cut open the film is carried out of the chamber to a compacting unit, so it cannot re-enter the product stream and occupies minimal volume in waste. The film path and the product path are separated by the chamber geometry, not by operator attention.
